1/2.9" 5MP CSP F2.4 DFOV 147 Degree M12 InnoMaker Lens
IMT Model No.  IMT-1B12D001-6


  Lens Model IMT-1B12D001-6
  Sensor Format 1/2.9"
  Resolution 5 MP
  Sensor Type CSP
  Structure 5G + IR Filter
  Max Image Circle Ø6.2
  F/NO. 2.4 +/- 5%
  EFL (mm) 2.50
  TTL (mm) 14.50
  FOV Field of View
  Diagonal DFOV 147°
  Horizontal HFOV 115°
  Vertical VFOV 70°
  TV Distortion <30.5%
  CRA <12°
  Lens Filter 650nm +/- 10nm @50%
  Barrel M12*P0.5
  KLT Camera Modules JAL-OV4689 V1.0
  Use IMT Made Lenses JAL-OV4689 V3.0


        IMT Lens Specification Sheet









         IMT Lens on KLT Camera Modules

        OmniVision OV4689 MIPI Interface Fixed Focus 4MP Camera Module
        Model No.  JAL-OV4689 V1.0


   Camera Module No. JAL-OV4689 V1.0
   Image Sensor OV4689
   EFL 2.50 mm
   F.NO 2.4
   Pixel 2688 x 1520
   View Angle 147°
   Lens Type 1/3 inch
   Lens Dimensions 13.70 x 13.70 x 15.32 mm
   Module Size 40.05 x 13.70 mm
   Module Type Fixed Focus
   Interface MIPI
   IMT Lens Model IMT-1B12D001-6
   Mating Connector AXK7L40223G



        OmniVision OV4689 MIPI Interface Fixed Focus 4MP Camera Module
        Model No.   JAL-OV4689 V3.0


   Camera Module No. JAL-OV4689 V3.0
   Image Sensor OV4689
   EFL 2.50 mm
   F.NO 2.4
   Pixel 2688 x 1520
   View Angle 147°
   Lens Type 1/3 inch
   Lens Dimensions 13.70 x 13.70 x 15.32 mm
   Module Size 40.05 x 13.70 mm
   Module Type Fixed Focus
   Interface MIPI
   IMT Lens Model IMT-1B12D001-6
   Mating Connector DF30FC-40DS-0.4V
