1/3" 5MP CSP F2.5 DFOV 170 Degree M12 InnoMaker Lens
IMT Model No.  IMT-1B12E004-N


  Lens Model IMT-1B12E004-N
  Sensor Format 1/3"
  Resolution 5 MP
  Sensor Type CSP
  Structure 5G + IR Filter
  Max Image Circle Ø6.4
  F/NO. 2.5 +/- 5%
  EFL (mm) 2.30
  TTL (mm) 20.10
  FOV Field of View
  Diagonal DFOV 170°
  Horizontal HFOV 130°
  Vertical VFOV 84°
  TV Distortion <35%
  CRA <14°
  Lens Filter 650nm +/- 10nm @50%
  Barrel M12*P0.5
  KLT Camera Modules KLT-KX2-OV13850 V1.0
  Use IMT Made Lenses KLT-KX5-IMX135 V1.0


        IMT Lens Specification Sheet









         IMT Lens on KLT Camera Modules

        OmniVision OV13850 MIPI Interface Fixed Focus 13MP Camera Module
        Model No.  KLT-KX2-OV13850 V1.0


   Camera Module No. KLT-KX2-OV13850 V1.0
   Image Sensor OV13850
   EFL 2.3 mm
   F.NO 2.5
   Pixel 4224 x 3136
   View Angle 170°
   Lens Type 1/3.06 inch
   Lens Dimensions 13.70 x 13.70 x 20.92 mm
   Module Size 40.05 x 18.00 mm
   Module Type Fixed Focus
   Interface MIPI
   IMT Lens Model IMT-1B12E004-N
   Mating Connector DF30FC-30DS-0.4V



        SONY IMX135 MIPI Interface Fixed Focus 13MP Camera Module
        Model No.   KLT-KX5-IMX135 V1.0


   Camera Module No. KLT-KX5-IMX135 V1.0
   Image Sensor IMX135
   EFL 2.3 mm
   F.NO 2.5
   Pixel 4224 x 3136
   View Angle 140°
   Lens Type 1/3.06 inch
   Lens Dimensions 13.7 x 13.7 x 20.92 mm
   Module Size 60 x 18.0 mm
   Module Type Fixed Focus
   Interface MIPI
   IMT Lens Model IMT-1B12E004-N
   Mating Connector FH12-30S-0.5SH
